CATIA V6 R2013X SOFTWARE

Instrument Images
ID0088

INSTRUMENT INCHARGE

Dr. Mohammed Rajik Khan

Professor

Geometric Modeling, CAD, CAE, Innovative Product Design, Human factors in Product Design, CAD based Industrial Ergonomics, Rapid Prototyping and Tooling, Electro Magnetic Welding, Bio-Mechanical

BASIC INFORMATION

  • Make & Model : Dassault Systems, USA
  • Department : Industrial Design
  • Location : CAD Lab
  • Category : Category - II
  • Status : Functional

PRINCIPLE:

Character line creation CATIA Imagine and Shape, a virtual clay modeler, allows users to easily create and modify character lines. Character lines are a key styling feature in automotive design that add definition and personality to a form. Collaborative design CATIA V6 allows multiple users to work on the same project simultaneously. This feature promotes real-time feedback and idea exchange, which can accelerate the design cycle. 3D design environment CATIA V6 is a platform for designing, simulating, and analyzing products in 3D. It allows designers and engineers to create complex shapes and intricate designs. Functional mock-up CATIA V6 expands CAD from physical product definition to functional mock-up. It takes into account multiple views that are required for product development. User-friendly interface CATIA V6 has a user-friendly interface with several features, including: Compass: A navigation hub in the corner of the screen that allows users to switch between workspaces Action bar: A customizable bar at the bottom of the screen that holds frequently used tools Specification tree: A tree on the left side of the screen that displays every part, feature, and sketch of a design in a hierarchy

APPLICATION:

Design and Drafting: CATIA is a powerful tool for designing complex parts and assemblies. It allows mechanical engineers to create 3D models and generate 2D drawings with accuracy and precision. It provides tools for sketching, modelling, and drafting that enable the design of components with intricate details.

EXPERIMENTS & CHARGES:

EXPERIMENT - 1

  • Name of Experiment : Create Designs in either 2D or 3D to visualise constructions
  • Condition of Analysis : As per MSDS & Cover Letter
  • Service Units : 1 Hour
  • Academic & Educational Institution Charges : ₹ 0.00
  • R & D National Laboratory Charges : ₹ 0.00
  • Industry Charges : ₹ 0.00
  • International Charges : ₹ 0.00
  • Available for Sample Booking : Yes
  • Remarks :
