NAME OF EQUIPMENT:
TMS 320C6748,FUNCTION GENERATOR

NAME OF EQUIPMENT:
DIGITAL STORAGE OSCILLOSCOPE (DSO),XDS DATA EMULATOR

NAME OF EQUIPMENT:
Solar Panel, Battery Setup, Dc Source, DC-DC Converter, DAB(2kw), Three Port Converter. (1 Kw),Buck Boost Converter(500W), BLDC Motor.

NAME OF EQUIPMENT:
1PHASE ENERGY METER, RHEOSTAT, SINGLE PHASE VARIAC, MI VOLTMETER, SINGLE PHASE TRANSFORMER, LPF WATTMETER, HPF WATTMETER, MI AMMETER, AC/DC LOAD BANK, POWER FACTOR DEMONSTRATOR KIT, INDUCTION LOAD BANK, CAPACITOR BANK, DC REGULATED POWER SUPPLY, MC AMMETER, MC VOLTMETER, 3-PHASE RHEOSTAT, POWER MEASUREMENT BY 2-WATTMETER METHOD KIT, PARALLEL CAPACITOR OF TWO SINGLE PHASE TRANSFERMER.

NAME OF EQUIPMENT:
Okaya Battery Module(240KW), DC Programmable Power Supply(10KW), LOHUM E-Rickshaw Battery, Resistive Load(20KW), IPMSM Motor, DSPACE, 3-Phase Autotransformer, 3-Phase Transformer., Interleaved Boost Converter(20KW), 3-Phase VSI, Induction Motor.

MAJOR EQUIPMENT:
DATA ACQUISITION CARD (USB-6009, 200MA MAX. DC, 8 INPUTS, 14 BIT) – 03 NOS, MAXWELL BRIDGE TRAINER (NV6533) – 01 NO, HAYS BRIDGE TRAINER (NV6535) – 01 NO, KELVIN BRIDGE TRAINER (NV6534) – 01 NO, SINGLE PHASE DIGITAL ENERGY METER (NV7025) – 01 NO, SOLAR ENERGY TRAINER WITH SOLAR PANEL (10V, 500MA, NVIS 6005) – 01 NO, STRAIN GAUGE TRAINER WITH WEIGHT (SCIENTECH2304, 600GMS.) – 01 NO. MAJOR SOFTWARE:
LABVIEW.

NAME OF EQUIPMENT:
Purge Box, Bath Sonicator, Wet Bench, Digital Weight Balance, Oven(2500c), Degicators, Spin Coater.

MAJOR EQUIPMENT:
CRO, SIGNAL GENERATOR.

MAJOR EQUIPMENT:
XILINX ARTIX 7 NEXYS 4 DDR BOARD (.PMOD AD2:
4-CHANNEL 12-BIT A/D CONVERTER, PMOD DA4: EIGHT 12-BIT D/A OUTPUTS) – 06 NOS, XILINX ZYNQ ULTRASCALE+ MPSOC ZCU104 EVALUATION KIT (CAMERA AND OTHER ACCESSORIES) – 01 NO, UNIVERSAL BURNER FOR MICROCONTROLLER – 01 NO, SPARTAN 6 FPGA DEVELOPMENT BOARD – 04 NOS, MOJO FPGA DEVELOPMENT BOARD – 04 NOS, TIVA™ C SERIES TM4C123G LAUNCHPAD EVALUATION KIT – 15 NOS, ARDUINO MEGA – 04 NOS.
MAJOR SOFTWARE:
UEF-SDSOC (25 USER LICENCE, PERMANENT SOFTWARE, LATEST VERSION) – 01 NO, VIVADO, PYTHON, MATLAB.

NAME OF EQUIPMENT:
Grid Simulator, Battery Inverter System, 4 Leg Inverter, DC-DC Converter, 4 Channel DSO.

NAME OF EQUIPMENT:
Schering bridge
High voltage power source, Capacitance and tan delta bridge.
Sphere gap
25cm sphere dia, 50cm sphere dia.
Acoustic sensor
One channel, Four channel.
Test transformer potential transformer
132KV/110KV
Current transformer
600-300-150/1A
High voltage transfermer(7.5 KVA), Voltage doubler circuit, Mark generator, Impulse control panel(400KV), Peak voltmeter, DSO.

NAME OF EQUIPMENT:
AUTO TRANSFERMER(20KVA), HV test transformer(220/100KV), Coupling capacitor(1000pf), Measuring capacitor(100pf), Partial discharge meter, Dso, Function generator, Pulse generator, 500KV TEST SETUP, Auto transformer(320KVA), Cascade transformer(500KVA), Coupling capacitor(1000pf), Measuring capacitor(100pf), Compensating reactor(50/100/150/200/250 KVAR), DTM partial discharge meter, Phase selector switch, Pd gold software, Break down voltage test set up.

NAME OF EQUIPMENT:
Work Station, MATLAB.

NAME OF EQUIPMENT:
DC MOTOR, DC GENERATOR, SINGLE PHASE TRANSFORMER, 3 PHASE TRANSFORMER, 3 PHASE GENERATOR, 3 PHASE SYNCHRONOUS MOTOR, 3 PHASE SLIPRING INDUCTION MOTOR, DC MOTOR AND 3 PHASE ALTERNATOR SET, 1 PHASE INDUCTION MOTOR, A SET OF 3 PHASE INDUCTION MOTOR AND DC MOTOR, WATTMETER(UPF), RHEOSTAT, AMMETER(MC), VOLTMETER(MC), 3 PHASE AUTOTRANSFORMER.

NAME OF EQUIPMENT:
DC MOTOR, A SET OF 3 PHASE INDUCTION MOTOR AND DC MOTOR, 1 PHASE TRANSFORMER, 3 PHASE TRANSFORMER, DC MOTOR AND 3 PHASE ALTERNATOR SET, 3 PHASE GENERATOR, OSCILLOSCOPE, CURRENT SENSOR, VOLTAGE SENSOR, AMMETER(MC), VOLTMETER(MI), CAPACITOR BANK, RHEOSTAT, WATTMETER(UPF).

MAJOR EQUIPMENT:
GUNN. OSCILLATOR (XG-11), PIN MODULATOR (XM-55), ISOLATOR (XI-621), FREQUENCY METER (XF-710), VARIABLE ATTENUATOR (XA-520), SLOTTED SECTION (XS-651), TUNEABLE PROBE (XP-655), DETECTOR MOUNT (XD-451), MATCHED TERMINATION (XL-400), GUNN POWER SUPPLY (GS-610), VSWR METER (SW-115), WAVE GUIDE STAND (XU-535), S. S. TUNER (XT-441), CABLE (BNC & TNC), COOLING FAN (2K25), KLYSTRON TUBE (2K25), KLYSTRON POWER SUPPLY (SKPS-610), KLYSTRON MOUNT (XM-251), UNIVERSAL WAVEGUIDE STAND (XU-535), CRO, DIGITAL STORAGE OSCILLOSCOPE (DSO), LCR METER, DIGITAL METER, PERSONAL COMPUTER, TRANSMISSION LINE TRAINER KIT
MAJOR SOFTWARE:
MATLAB

MAJOR SOFTWARE:
TCAD SENTAURUS (SYNOPSIS MAKE), VISUAL TCAD (COGENDA MAKE).

NAME OF EQUIPMENT:
Micro Wave Oven, Solar Panel

NAME OF EQUIPMENT:
SCR, MOSFET & IGBT TRAINER KIT, SINGLE PHASE HALF CONTROLLED BRIDGE CONVERTER, SINGLE PHASE FULL CONTROLLED BRIDGE CONVERTER, SINGLE PHASE IGBT BASED PWM INVERTER, DC-DC BUCK CONVERTER, DC-DC BOOST CONVERTER, DC-DC BUCK BOOST CONVERTER, THREE PHASE INDUCTION MOTOR WITH DRIVE FOR SPEED CONTROL, THREE PHASE HALF CONTROLLED BRIDGE CONVERTER, THREE PHASE FULL CONTROLLED BRIDGE CONVERTER.

NAME OF EQUIPMENT:
DC MOTOR WITH SPEED CONTROLLER KIT, DC-DC FORWARD CONVERTER, DC-DC INTER LEAVED BOOST CONVERTER, DC-DC SEPIC CONVERTER, DC-DC BI-DIRECTIONAL CONVERTER, ZVS TRAINER KIT, ZCS TRAINER KIT, THREE PHASE SCR MODULE, FLYBACK CONVERTER, FACTS CONTROLLER, DSPACE CONTROLLER CP1104, SHUNT ACTIVE FILTER, THREE PHASE INVERTER.

NAME OF EQUIPMENT:
ELECTRO MECHANICAL OVER CURRENT RELAY TEST KIT,NUMERICAL OVER CURRENT RELAY TEST KIT,ELECTRO MECHANICAL UNDER VOLTAGE RELAY TEST KIT,ELECTRO MECHANICAL OVER VOLTAGE RELAY TEST KIT,TRANSMISSION LINE SIMULATION STUDY PANEL,POWER TRANSMISSION AND DISTRIBUTION SIMULATION UNIT,ENERGY UTILIZATION SETUP

NAME OF EQUIPMENT:
MOTOR PROTECTION RELAY SIMULATION PANEL, RADIAL FEEDER PROTECTION SIMULATION PANEL, GENERATOR PROTECTION SIMULATION PANEL, TRANSMISSION LINE SIMULATION STUDY PANEL, TRANSFORMER PROTECTION STUDY PANEL, 3 PHASE ENERGY METER TEST KIT, POWER TRANSMISSION AND DISTRIBUTION SIMULATION UNIT, ENERGY UTILIZATION SETUP.

NAME OF EQUIPMENT:
Power Quality Analyser, Programmable 3 Phase AC Power Supply., Opal RT Test Setup OP4510, Solar Array Simulator, Dspace Microlab Box, 4 Leg Semikron Inverter Modules, DC-DC Converter Modules.

NAME OF EQUIPMENT:
Thermal Evaporation, Chiller (1 Ton), Vacuum Pumping System (Upto 10-6 Mili Bar), Furnace (12000c,9000c), Gas Sensing Chamber(Testing).

Major Equipment: Keysight Digital Storage Oscilloscope (Dsox2024a) 200 Mhz 2gsa/S – 06 Nos, Tektronix Digital Storage Oscilloscope (Tds2022b) 200mhz – 04 Nos, Emona Telecoms–Trainer (Ett – 01) – 08 Nos, Tektronix Mixed Signal Oscilloscope (Mso 4054) – 01 No, Keysight Mixed Signal Oscilloscope (Siglent Sds-2204x Plus (Mso+Afg) – 01 No, Benchmark Wicomm–T–Sdr Based Wireless Digital Communication System – 01 No, Agilent Series Spectrum Analyser (E4402b) 9 Khz – 3 Ghz – 01 No, Agilent Series Signal Generator (E4430b) 250 Khz – 1 Ghz – 01 No, Keysight Field Fox Portable Spectrum Analyser (9 Khz To 7 Ghz) – 01 No, National Instrument Usrp-2940r With Accessories – 01 No, National Instrument Usrp-2942 – 01 No. (In Process For Procurement), Basic Sdr Training System – 02 Nos. (In Process For Procurement), Advance Sdr Training System – 02 Nos. (In Process For Procurement), Lenovo, Hp, Dell Personal Computers (7 For Pg Research & 4 For Lab.) – 11 Nos.
Major Software: Keysight Systemvue Esl Software(Perpetual) – 01 No.

MAJOR EQUIPMENT:
COMPUTER SYSTEMS WITH INTEL CORE I5 VPRO PROCESSOR, 500 GB HARD DISK, 6 GB RAM – 71 NOS.
MAJOR SOFTWARE:
MATLAB R2018A, R2018B, R2019A, R2019B, MULTISIM V13.0, V14.1, LABVIEW, PYTHON, ARDUINO.

MAJOR EQUIPMENT:
COMPUTER SYSTEMS WITH INTEL CORE I5 VPRO PROCESSOR, 500 GB HARD DISK, 4 GB RAM – 26 NOS, COMPUTER SYSTEMS WITH INTEL CORE I7 VPRO PROCESSOR, 500 GB HARD DISK, 4 GB RAM – 12 NOS.
MAJOR SOFTWARE:
MATLAB R2018A, R2019B.
